Display Unit: 2.05 x 2.59 x 6.3 in / 52.1 x 65.8 x 160 mm
Drive Unit: 4.5 x 9 x 1 in / 115 x 23 x 26 mm
Mass: 1.1 lbs / .5 kg
Increased measuring efficiency capable of displaying results and setting conditions via wireless communication when used with option accessory U-WAVE-TIB
Built-in 2.8-inch color graphic, back-lit LCD display provides excellent readability, improved visibility and is easy-to-use in dark environments
Operation keys are clearly defined on the front of the unit and under the sliding cover
Internal memory stores up to 10 measurement conditions and one measured profile
An optional memory card can be used to store large quantities of measured profiles and conditions
Password protection prevents unintended operations and protects instrument settings
The display interface supports 16 interchangeable languages
LCD display mode can be freely switched between portrait and landscape as well as left-hand or right –hand direction
The Surftest SJ-220 complies with the following standards: ISO (ISO 21920, ISO 4287:1997, ISO 13565:1996, ISO 12085:1996, ISO 21920:2021), JIS (JIS B0601:1982, JIS B 0601:1994, JIS B 0601:2013, JIS B 0671:2002, JIS B 0631:2000), ASME B46.1, VDA2006, and Switchable
